This section lists the supplemental characteristics of the Keysight N6705C DC Power Analyzer.
Supplemental characteristics are not warranted but are descriptions of performance determined
either by design or by type testing. All supplemental characteristics are typical unless otherwise
noted.
Specifications and characteristics are subject to change without notice.
Complete specifications and supplemental characteristics information for all power
modules are included in the Keysight N6700 DC Power Analyzer Family
Specifications Guide.
Supplemental Characteristics
Characteristic Keysight N6705C
Maximum total power available for
power modules: 600 W
Front panel outputterminals maximum
current rating: 20 A
BNC trigger connectors
IO:
Maximum voltage:
Minimum input pulse:
Output pulse:
Digital TTL level compatible
5 V
> 6 ns, positivegoing; > 90 ns, negative going
10 ms, negative-going
USB current ratings
Front panel USB:
Rear panel USB:
200 mA
300 mA
Data storageof internal flash memory:
4 Gbytes
Protection Response
INH Input:
Fault on coupled output:
5 µs from receipt of inhibit to start of shutdown
< 10 µs from receipt of faultto start of shutdown
Command Processing Time: ≤ 1 ms from receipt of command to start of outputchange
