[SOURce:]LIST:DWELl <value>{,<value>}, (@<chanlist>)
[SOURce:]LIST:DWELl? (@<chanlist>)
Specifies the dwell time for each list step. Dwell time is the time that the output will remain at a
specific step. Dwell times can be programmed from 0 through 262.144 seconds with the following
resolution:
Range in seconds Resolution
0 - 0.262144 1 microsecond
0.262144 - 2.62144 10 microseconds
2.62144 - 26.2144 100 microseconds
26.2144 - 262.144 1 millisecond
A comma-delimited list of up to 512 steps may be programmed. At the end of the dwell time, the
output state of the unit depends upon the [SOURce:]LIST:STEP program settings.
Parameter Typical Return
0 – 262.144,
*RST 1 step with a valueof 0.001
<list value 1>,
<list value 2>,
<list value 3>...
Programs a dwell list. Thelistcontains 3 steps: LIST:DWEL 0.2,0.8,1.6, (@1)
l The order in which the list values are entered determines the sequence when the list executes.
l To create a valid list, the Voltage, Current, BOST, EOST, and Dwell lists must all be the same
length or have a length of 1, which is interpreted as having the same length as the longest list.
l This command overwrites any previously programmed list; it does not append to the previous list.
[SOURce:]LIST:CURRent:POINts? (@<chanlist>)
[SOURce:]LIST:DWELl:POINts? (@<chanlist>)
[SOURce:]LIST:VOLTage:POINts? (@<chanlist>)
[SOURce:]LIST:TOUTput:BOSTep:POINts? (@<chanlist>)
[SOURce:]LIST:TOUTput:EOSTep:POINts? (@<chanlist>)
Returns the number of list points (same as steps). The queries do not return the point values.
Parameter Typical Return
Returns the number of points in the current list: LIST:CURR:POIN? (@1)
Returns the number of points in the dwell list: LIST:DWEL:POIN? (@1)
Returns the number of points in the voltage list: LIST:VOLT:POIN? (@1)
Returns the number of points in the BOST list: LIST:TOUT:BOST:POIN? (@1)
Returns the number of points in the EOSTlist: LIST:TOUT:EOST:POIN? (@1)
Keysight N6705C Operating and Service Guide 297
7 SCPI Programming Reference
