Reference
Designator
N6705C Part number Description
38 5185-8810 Bulk supply to line switch cable
39 5185-8823 Processor carrier to front panel cable
40 N1912-61002 Backlight cable assembly
41 5185-8824 Bulk supply ground wire
47 5067-4311 (2) Bias to backplane 1; Bias to backplane 2
48 5185-8825 Filter to line switch cable
49 D8104-61602 Front panel USB cable
50 5067-5095 (2) Auxiliary voltage PCA
51 9170-2264 (4) Front panel cable inductor
52 0510-1350 (4) Rear panel cable grommet
53 1510-0038 Ground binding post
54 5188-4226 AC filter module (with 1M ohm resistor)
55 5003-1139 Heat spreader for P600 processor
Handle parts and label
5041- 7902 End cap
E6601-21033 Round handle retainer
5063-1581 Strap handle with insert
N6705-80011 Rear mainframe label
9 Service and Maintenance
468 Keysight N6705C Operating and Service Guide
