66 PWR-01
Basic Features ｜ CONFIG Settings
CF60 (BOOT) LAN setting reset (LCI/ dEF)/ apply (APPL)
Sets whether to reset or apply the LAN interface settings (p.57).
Then, press SET twice to execute the reset or application.
If you select to reset the LAN interface settings (LCI (LCI)/ DEF (Default)), the security
password will be cleared, and the PWR-01 will be in a security-disabled state.
If the LAN LED turns red (p.9), set the settings again.
For details on the LAN interface settings, see the “Communication Interface Manual” on the
included CD-ROM.
CF61 (ADR) IP address assignment method
Sets the IP address assignment method.
Set whether to use (on: 1) or not use (off: 0) the following: DHCP server, AUTO IP function
(automatic assignment), and MANUAL IP function (manual assignment).
If DHCP and AUTO IP are both set to on and an IP address is not assigned through a DHCP
server, AUTO IP is used.
To use MANUAL IP, set DHCP and AUTO IP to off. The IP address that is assigned by the
AUTO IP function is 169.254.x.x (where x is a number between 1 and 254).
This parameter is applied when you turn the POWER switch off and on or when you execute
APPL (Apply) with CF60.
CF62 to CF65 (S.IP1 to S.IP3) Manual IP address setting (MANUAL IP)
If you are not using the DHCP server or the AUTO IP function, set the IP address manually.
To do so, use CF61 to set MANUAL IP to on.
This parameter is applied when you turn the POWER switch off and on or when you execute
APPL (Apply) with CF60.
Display Description
LCI LAN Configuration Ini-
tialize
Resets the LAN interface settings (to their factory default
values)
DEF Default The LAN interface and multichannel (VMCB) settings are
reset (to their factory default values).
APPL Apply The LAN interface is restarted, and the CONFIG settings are
applied.
Display Description
001 001 DHCP: off, AUTO IP: off, MANUAL IP: on
010 010 DHCP: off, AUTO IP: on, MANUAL IP: off
011 011 DHCP: off, AUTO IP: on, MANUAL IP: on
100 100 DHCP: on, AUTO IP: off, MANUAL IP: off
101 101 DHCP: on, AUTO IP: off, MANUAL IP: on
110 110 DHCP: on, AUTO IP: on, MANUAL IP: off (factory default setting)
111 111 DHCP: on, AUTO IP: on, MANUAL IP: on
Parameter
number
Display Description
CF62 0. to 255 0 to 255 First octet of the IP address
CF63 0. to 255 0 to 255 Second octet of the IP address
CF64 0. to 255 0 to 255 Third octet of the IP address
CF65 0. to 255 0 to 255 Fourth octet of the IP address
