2.15.8 Fuse
D
evice
G
is assembled on cylinder head
P
(flywheel side);
it protects the electrical circuit in the event of an overload
or short circuit.
N
OTE:
Component not necessarily supplied by
KOHLER.
Fig 2.41
2.15.9 Control panel (optional)
P
anel L can be assembled on the engine or machine.
The connectors are described in Tab. 2.36, the main
functions are illustrated.
NOTE: Component not necessarily supplied by KOHLER.
Tab 2.36
POS.
DESCRIPTION
M
Hour-meter indicator
S
Control switch to start the engine
W1
Panel ignition indicator
W2
Warning Light - battery not charging
W3
Warning Light - engine oil not pressurised
W4
Warning Light - high coolant temperature
W5
Warning Light - alarm general indicator
Fig 2.42
