TECHNICAL INFORMATION
EN 14
FUEL SUPPLY SYSTEM
GENERAL INFORMATION
UNIT OF
MEASURE
KDI 2504 T M
Type of fuel Diesel UNI-EN590 - ASTM D975
High-pressure fuel injection pump
STANADYNE - DB
Fuel supply
Low pressure electric pump
Fuel filter
Filtering surface
cm
2
2300
Degree of filtration
µm
5
Maximum pressure at injection pump inlet
bar
< 0.5
LUBRICATION CIRCUIT
GENERAL INFORMATION
UNIT OF
MEASURE
KDI 2504 T M
Fuel
Lubrication
See Par. 2.4
Circuit forced Lobe pump
Oil sump capacity (MAX)
Lt.
11,5
Oil pressure switch
Intervention pressure (MIN)
bar
0.8±0.1
Oil filter
Maximum operating pressure
bar
7.0
Degree of filtration
µm
17±2
Filtering surface
cm
2
1744
COOLING CIRCUIT
GENERAL INFORMATION
UNIT OF
MEASURE
KDI 2504 T M
Coolant %
See Par. 2.6
Water pump
Lt./min
75
Thermostatic valve
Opening temperature
°C
+79
Stroke at 91°C
mm
7.50
Liquid recirculation
Lt./h
9
ELECTRICAL SYSTEM - ELECTRIC FAN
GENERAL INFORMATION
UNIT OF
MEASURE
KDI 2504 T M
Circuit rated voltage
V
12
External alternator (rated current)
A
80
Starter motor power
kW
2
System electrical consumption, excluding:
heater, electric pump, electric fan, starter
W 24
