Kohler KDI 2504TM

FLUIDS FILLING INFORMATION
10
147
EN
10 FLUIDS FILLING INFORMATION
10.1 Engine oil
Important
•
Before proceeding with operation, read
Par. 3.3.2.
•
Do not use the engine with the oil level
below the minimum.
1.
Loosen the oil filler cap A or the oil filler
cap C if the cap A is not accessible.
2.
Add the type and amount of oil
recommended (Tab. 2.2).
Fig 10.1
3.
Remove the oil dipstick B and check that
the level is up to but does not exceed th
e
MAX.
4.
If the oil level is not at MAX, insert more
oil until the MAX level is reached as
indicated on the dipstick.
5.
Re-tighten the cap A or C.
NOTE: See the Par. 11.1 for the various
configurations of the oil dipstick.
Fig 10.2
NOTE:
Click on the right to play the procedure.
