INFORMATION ABOUT OPTIONAL
COMPONENTS
11
153
EN
•
Always replace the washer H every time it is
disassembled.
Modified component, see service letter 700019 -
700021.
•
Check that the perforated screw A is free from
impurities inside it.
3.
Position the gear unit B on the hole J using the bushing
G to centre.
4.
Secure the gear B using the screw A inserting the
washer H (tightening torque at see service letter
700019 - 700021).
Fig 11.11
11.4 3rd PTO (replacement)
F
ig 11.12
