Kohler KDI 2504TM Workshop Manual

INFORMATION ON ADJUSTMENTS
12
169
EN
12 INFORMATION ON ADJUSTMENTS
12.1 Air filter check
Important
•
Before proceeding with operation, read Par. 3.3.2.
1.
Hose A must be completely clean and not damaged.
2.
Air filter cartridge B and its housing C must be
completely clean and free from impurities.
Fig 12.1
12.2 Rubber hose and manifold control
Important
•
Before proceeding with operation, read Par. 3.3.2.
The check is carried out by applying slight deflection or bending
along the tube/hose and next to the hose clamps.
Components must be replaced if they have clear signs of cracks,
tears, cuts, leaks, or do not retain a certain degree of elasticity.
1.
Check the condition of all rubber hoses A.
2.
Check whether there are any leakages of air, water, oil or
fuel next to their connections.
Fig 12.2
Fig 12.3
