13
TOOLS INFORMATION
EN 172
13 TOOLS INFORMATION
13.1 Information regarding specific tools
In Tab 13.1 - 13.2 there is a list of all the specific tools that are required and approved to carry out
operations of disassembly - assembly - regulations - settings - repairs on engine series KDI, correctly and
safely.
Warning
• KOHLER declines all responsibility for any damage to the engine, persons, or things caused by the
u
se of different types of tools to those indicated in Tab 13.1 - 13.2, where referred to them in the
manual.
SPECIAL TOOLS FOR DISASSEMBLY AND ASSEMBLY
ST_03
Piston protrusion - injectors cylinder head
surface control tool
ED0014602980-S
ST_04
High-pressure fuel injection pump puller gear
ED0014603680-S
ST_05
Spanner for capscrews Six nicks SN 8
ED0014603650-S
ST_06
Spanner for capscrews Six nicks SN 5
ED0014603640-S
ST_07
Tool for disassembling / reassembling valves
ED0014603720-S
ST_08
Tool for gasket valve stem
ED0014603660-S
