Kohler KDI 2504TM

7
INFORMATION FOR DISASSEMBLY
EN 86
2.
Remove the rotors P and Q.
Fig 7.17
7.7.5 Gruppo Oil Cooler e filtro olio
1.
Follow operations of Par. 6.6.1.
W
arning
•
Use a suitable container to recover any residue oil.
7.7.6 Oil vapour separator unit
1 -
Follow operations of
Par. 6.8.1.
Warning
•
Use a suitable container to recover any residue oil.
7.8 Intake manifold disassembly
1.
Undo the screws C and remove the manifold D togethe
r
w
ith the washer E.
Fig 7.18
