Kohler KDI 2504TM

11
INFORMATION ABOUT OPTIONAL
COMPONENTS
EN 156
11.5 4th PTO (replacement)
F
ig 11.21
Important
•
Before proceeding with operation, read Par. 3.3.2.
11.5.1 Disassembly
1.
Undo the screws A and remove the pump B.
Fig 11.22
2.
Undo the screws C and remove the flange D.
Fig 11.23
