Kohler KDI 2504TM

9
ASSEMBLY INFORMATION
EN 130
9.8 Fuel system assembly
Important
•
Replace the high pressure pipes after two
disassemblies.
•
Remove the protective caps from all th
e
c
omponents of the fuel circuit just before
assembly (Par. 2.9.7).
•
W
hen repaired, RSN-A injectors must be
certified by a Stanadyne centre to check their
correct operation - check the type of engine
m
ounted injectors on the spare parts lis
t
(RSN-A is specified in the description).
Fig 9.59
9.8.1 Injector
1.
Lubricate the gaskets U, T, S, and fit them o
n
the
injector Z.
Fig 9.60
2. Fit the injector
Z
in the sleeve
V
.
Fig 9.61
3.
Assemble parts P, Q, R.
4.
Fit the parts so assembled on the injector Z.
Fig 9.62
