7
INFORMATION FOR DISASSEMBLY
EN 84
1.
Undo the screws D and remove the thermostatic valv
e
c
over E.
2.
Remove the thermostatic valve F and its gasket.
I
mportant
•
Always replace the gasket G every time it is
disassembled.
3.
Check that the air bleeding hole is not clogged or
blocked (Par. 2.11.3).
Fig 7.10
7.5.3 Coolant recirculation components disassembly
Im
portant
•
The pump B is not reparaible
1.
Undo the screws A and remove the water pump unit B
with its gasket C.
Fig 7.11
7.6 Crankshaft pulley disassembly
NOTE:
Perform the operations described in
Par. 6.1.5 points 2
and 3.
1.
Undo the screw A (clockwise - as seen from the timing
system side - Ref. A Par. 1.3) and remove the pulley B.
