Kohler KDI 2504TM Workshop Manual

11
INFORMATION ABOUT OPTIONAL
COMPONENTS
EN 168
11.11.5 Flange plate / housing assembly
1.
Execute the operations described in point 6
of Par. 11.11.4.
2.
Fasten housing or plate L by using
capscrews A and strictly following the order
s
hown in Fig. 11.61 (tightening torque at 8
5
Nm)
.
3.
Fasten housing or plate L by using
capscrews B (tightening torque at 270 Nm).
11.11.6 Flywheel assembly
1.
Execute the operations described in Par.
9.5.2.
Fig. 11.61
