9
ASSEMBLY INFORMATION
EN 146
Component
Thread
(mm)
Torque (Nm)
Sealer
Side feet fastening capscrew (on flange bell or
crankcase)
M12x1.75
50
Rear feet fastening capscrew
M16x1.5
200
OIL SUMP WITH SUPPORTING STRUCTURE
Component
Thread
(mm)
Torque (Nm)
Sealer
Flange bell fastening capscrew
M10x1.5
85
Flange bell fastening capscrew
M16x2
270
Oil sump fastening capscrew
M8x1.25
47
By-pass tube fastening capscrew
M6x1
10
