Kohler KDI 2504TM Workshop Manual

ASSEMBLY INFORMATION
9
145
EN
BALANCE DEVICE (4 CYLINDERS)
Component
Thread
(mm)
Torque (Nm) Sealer
Housing closing panel fastening capscrew M6x1 8
Shafts support fastening capscrew M10x1.5 50
REMOTE OIL FILTER
Component
Thread
(mm)
Torque (Nm) Sealer
Head fastening and Oil Cooler union on crankcase M20x1.5 25
Loctite
2701*
Crankcase head nipple and oil filter support
M14x1.5
40
Tube union on crankcase head
G3/8
30
Tube union on filter support
G3/8
35
Oil filter M20x1.5 20
Filter support head air bleeding cap M8x1.25 25
INTAKE CIRCUIT
Component
Thread
(mm)
Torque (Nm) Sealer
Air filter support plate fastening capscrew (on flange
bell)
M8x1.25 25
Air filter support fastening capscrew
M8x1.25
25
EXHAUST CIRCUIT
Component
Thread
(mm)
Torque (Nm) Sealer
Muffler brace support fastening capscrew
M8x1.25
25
Muffler fastening capscrew on muffler
M8x1.25
25
Muffler fastening nut
M8x1.25
25
COOLING CIRCUIT
Component
Thread
(mm)
Torque (Nm) Sealer
Blower fastening capscrew M6x1 10
Radiator support fastening capscrew M16x1.5 150
Shroud radiator fastening capscrew
M6x1
10
Radiator lower brace fastening capscrew
M8x1.25
25
Radiator on anti-vibrating
M8x1.25
25
Anti-vibrating radiator fastening nut (on lower brace)
M8x1.25
25
Anti-vibrating and brace fastening capscrew (upper)
M6x1
10
Upper brace fastening capscrew (on engine cylinder
head)
M8x1.25 25
Side bulkheads fastening capscrew M6x1 10
ENGINE SUPPORT
