Kohler KDI 2504TM Workshop Manual

9
ASSEMBLY INFORMATION
EN 144
Component
Thread
(mm)
Torque (Nm) Sealer
Accelerator bracket fastening capscrew M6x1 10
* Alternatively to the capscrew replacements, with "Dri-loc"
OPTIONAL COMPONENTS (CHAP. 11)
OIL DIPSTICK ON CYLINDER HEAD
Component
Thread
(mm)
Torque (Nm) Sealer
Oil dipstick tube fastening capscrew
M6x1
10
HEATER
Component
Thread
(mm)
Torque (Nm) Sealer
Flange intake with heater fastening capscrew
M8x1.25
22
ALTERNATOR WITH POLY-V BELT
Component
Thread
(mm)
Torque (Nm) Sealer
Pulley fastening capscrew
M10x1.5
48
Pulley positioning blocking nut capscrew
M10x1.5
45
Alternator brace fastening capscrew
M8x1.25
25
Alternator fastening capscrew (upper)
M8x1.25
25
Alternator fastening capscrew (lower)
M8x1.25
40
Pulley sliding plate fastening capscrew
M8x1.25
25
IDLE GEAR (FOR 3TH /4TH PTO)
Component
Thread
(mm)
Torque (Nm) Sealer
Gear drilled fastening capscrew M14x1.5
Consultare il Par.
>>
Molyslip
3
TH
PTO
Component
Thread
(mm)
Torque (Nm) Sealer
Pump support fastening capscrew M8x1.25 25
Loctite
2701*
Pump fastening capscrew M8x1.25 25
4
TH
PTO
Component
Thread
(mm)
Torque (Nm) Sealer
Grooved crankshaft support fastening capscrew M8x1.25 25
Loctite
2701*
Cover fastening capscrew (3
rd
PTO side)
M8x1.25
25
Sump support fastening capscrew
TG6
10
Pump fastening capscrew
M8x1.25
25
