Kohler KDI 2504TM Workshop Manual

ASSEMBLY INFORMATION
9
143
EN
EXHAUST MANIFOLD
Component
Thread
(mm)
Torque (Nm) Sealer
Exhaust manifold fixing stud M8x1.25 25
Exhaust manifold fixing nut M8x1.25 25
Exhaust flange/muffler fixing nut
M8x1.25
25
LUBRICATION CIRCUIT
Component
Thread
(mm)
Torque (Nm) Sealer
Oil filter fastening union M20x1.5 15
Loctite
2701*
Oil filter
M20x1.5
15
Oil pump carter fastening capscrew
TG6
10
Carter distribution fastening capscrew M8x1.25 25
Fastening capscrew for plug on timing system cover TG6 10
Side oil load flange fastening capscrew (onto carter
distribution)
TG6 10
Pressure relief valve cap
M16x1.5
50
Breather system cover fastening capscrew (on rocker arms
cover)
M8x1.25 25
CRANKSHAFT PULLEY
Component
Thread
(mm)
Torque (Nm) Sealer
Crankshaft pulley fastening screw
M16x1.5
360
Molyslip
COOLANT CIRCUIT
Component
Thread
(mm)
Torque (Nm) Sealer
Thermostatic valve cover fastening capscrew
M6x1
10
Coolant pump fastening capscrew
M8x1.25
25
ELECTRICAL COMPONENTS
Component
Thread
(mm)
Torque (Nm) Sealer
Coolant temperature sensor
M12x1.5
20 max.
Oil pressure switch
M12x1.5
35
Sensor for water presence in fuel 5
Alternator bracket fastening capscrew
M8x1.25
25
Alternator fastening capscrew
M8x1.25
40
Alternator fastening capscrew
M10x1.5
69
Starter motor fastening capscrew
M10x1.5
45
Supply cable fastening nut (starter motor)
M8x1.25
10
CONTROLS
