FLUIDS FILLING INFORMATION

149

12.

After a few hours of operation stop the engine and

allow it to cool.

Check and top up the coolant liquid.

Fig 10.6

NOTE:

Click on the right to play the procedure.

https://www.youtube.com/embed/XuR1t

lU2zmo?rel=0
