INFORMATION FOR DISASSEMBLY
EN 88
7.9.4 Injector
1.
Undo the screws P and remove the washers Q and the
brackets M.
2.
Pull out the injectors N.
NOTE
: Should you be unable to remove the injector (acting
only on point
BC
), use an open-ended spanner (
∅
11 mm
), by
applying small rotations to unblock the component. If the
washer
K
is not found on the injector
N
, recover it from inside
the injector sleeve
J
.
Fig 7.22
7.9.5 Injection pump
Important
•
Before disassembling, carefully read Par. 2.17.
•
The injector pump cannot be repaired.
1.
Carry on operations described in steps 1-13 Par. 6.1.5.
2.
Undo the nut S and remove it together with the washer.
3.
Screw the unit ST_04 on the gear R.
Fig 7.23
4.
Undo the screws T.
5.
Tighten the screw U of the unit in order to separate the
injector pump S from the high pressure pump control
gear R.
Fig 7.24
Fig 7.25
NOTE:
Click by side to play the procedure.
