Kohler KDI 2504TM Workshop Manual

INFORMATION FOR DISASSEMBLY
7
91
EN
7.12.1.1 Rocker arm ( )
1.
R
emove the retainer snap ring C.
2.
Remove the shoulder rings D.
3.
Remove the rocker arms E and springs.
Fig 7.31
7.12.2 Rods and u-bolts
1.
Remove the valve control U-bolts H.
2.
Remove the rocker arm control rods L.
Fig 7.33
7.12.3 Cylinder head
I
mportant
•
Wait for the engine to reach ambient temperatur
e
b
efore to remove the head in order to prevent
deforming.
•
The cylinder head fastening bolts M must be replaced
every time they are disassembled.
1.
Undo the bolts M.
2.
Remove the cylinder head N.
I
mportant
• Only use the eyebolts
AE
installed by
KOHLER
to move the
cylinder head
Q.
3. Remove the head gasket P.
Fig 7.34
Fig 7.35
