Kongsberg Simrad EK80 - Page 101

394149/D
99
Tolearnmoreaboutthevariousvideostandards,exploretheseWikipediapages.
•DVI
•HDMI
•DisplayPort
4ConnectthecablefromtheProcessorUnittothekeyboard.(C6)
5ConnectthecablefromtheProcessorUnittothemouse(oranothersimilardevice).
(C7)
6ConnecttheEthernetcablefromtheProcessorUnittotheWideBandTransceiver
(WBT).(C8)
Note
Itisveryimportantthatahigh-qualityEthernetcableisused.Youmustuse
CAT-5ESTP(ShieldedTwistedPair)qualityorbetter .Ifyouuseacablewith
lowerbandwidthcapacityyouwillreducetheEK80performance.Donot
connect
theProcessorUnittotheWideBandTransceiver(WBT)usinganexistinglocal
areanetwork(LAN).
Dependingontheoperationalrequirements,oneormoreWideBandTransceiver
(WBT)unitsmaybeusedinthecompleteEK80system.AnEthernetswitchis
requiredifmorethanoneWideBandTransceiver(WBT)isused.
Formoreinformation,seethecabledetails:
•RJ45HighspeedEthernetcable(1000Base-t),page147
7ConnecttheEthernetcablefromtheProcessorUnittothelocalareanetwork
(LAN).(C9)
Formoreinformation,seethecabledetails:
•RJ45HighspeedEthernetcable(1000Base-t),page147
8ConnecttheserialcablesfromtheProcessorUnittotherelevantexternaldevices.
(C10)
Formoreinformation,seethecabledetails:
•Cabledrawingsandspecications,page136
9Ifapplicable,connectthesignalcablefromtheProcessorUnittothesynchronization
system.(C10)
Formoreinformation,seethecabledetails:
•K-SyncinterfacetogenericRS-232synchronizationinput,page148
•SimradTU40interfacetogenericRS-232synchronizationinput,page151
Relatedtopics
InstallingtheEK80cables,page97
Cablelayoutandinterconnections,page85
Cablelayoutandinterconnections
