Kongsberg Simrad EK80 - Turning on the EK80 for the First Time; Setting up Summary

394149/D
199
TurningontheEK80forthersttime
Topics
Settingupsummary,page199
InstallingtheEK80operationalsoftware,page201
TurningontheEK80toPassivemode,page202
Obtainingandinstallingthesoftwarelicense,page203
DeningtheIPaddressontheProcessorUnitnetworkadapterforcommunication
withthetransceiver,page205
Installingoneormoretransducers,page206
Installingtransceiverchannels,page210
Adjustingthescreenresolution,page212
Settingupsummary
BeforeanewEK80Widebandscienticechosoundercanbeputtouse,itmustbe
setupforoperation.
Prerequisites
•TheEK80Widebandscienticechosoundersystemunitshaveallbeeninstalled
accordingtotheinstructionsprovided.
•Allcableshavebeenconnectedandveried.
•Allsystemunitshavebeeninspected.
•TheEK80operationalsoftwareisavailable.
•TheEK80softwarelicenseisavailable.
Caution
YoumustneversettheEK80to"ping"unlessthetransducerissubmergedinwater.
Mosttransducersaredamagedbeyondrepairiftheytransmitinopenair.Prevent
inadvertentuseoftheEK80wheneveratransducerisnot submerged.
Procedure
1Dothefollowingpreparations.
aTurnontheProcessorUnit.
bMakesurethatyouhaveadministrativerights.
cSwitchoffanyrewallapplications.
Settingtowork
