Kongsberg Simrad EK80 - Supported Datagram Formats for Motion Information

394149/D
285
•SimradDBS
SimradDBSisaproprietarydatagramformatcreatedbyKongsbergMaritimeto
providethecurrentdepthofthetrawlsensor.
•SimradHFB
SimradHFBisaproprietarydatagramformatcreatedbyKongsbergMaritime.It
providestheverticaldistance(height)fromtheheadropetothefootrope,andfromthe
headropetothebottom.TheheightsaremeasuredbyanITITrawlEyeoraheight
sensor.Ifyouusetwoheightsensors,theinformationfromthesecondsensoris
providedintheSimradHB2datagram.
•SimradTDS
SimradTDSisaproprietarydatagramformatcreatedbyKongsbergMaritimeto
providethedoorspread.Thatisthedistancebetweenthetwotrawldoors.Inadual
trawlsystem,thedistancebetweentheseconddoorsetisprovidedintheSimrad
TS2datagram.
•SimradTPR
SimradTPRisaproprietarydatagramformatcreatedbyKongsbergMaritime.It
providestherelativebearingandwaterdepthofthetrawlsensor,aswellasits
distancefromthevessel.Thebearingresolutionis1degree.TheSimradITImeasures
thedepthdifferentlyfromtherangeandthebearing.IftheITIonlyknowstherange
andthebearing,thedeptheldisempty.
•SimradTPT
SimradTPTisaproprietarydatagramformatcreatedbyKongsbergMaritimeto
providethetruebearingandwaterdepthofthetrawlsensor,aswellasitsdistance
fromthevessel.Thebearingresolutionis1degree.
Relatedtopics
Interfacespecications,page281
Technicalspecications,page279
Supporteddatagramformatsformotioninformation
TheEK80willinterfacewithperipheralsystemsandsensorsusingstandardand/or
proprietarydatagramformats.Whenenabled,thenavigationalinformationonthetop
barincludesthevessel’scurrentroll,pitchandheavemovements.
TheEK80supportsthefollowing
datagramformatsfromamotionsensor.
•KMBinary
KMBinaryisagenericdatagramformatdenedbyKongsbergMaritime.Thisformat
hasveryhighresolutionontimingandsensorparameters.
Technicalspecications
