280

394149/D

Introductiontotechnicalspecications

Thesetechnicalspecicationssummarizethemainfunctionalandoperational

characteristicsoftheEK80Widebandscienticechosounder.Theyalsoprovide

informationrelatedtopowerrequirements,physicalpropertiesandenvironmental

conditions.

TheEK80softwaresupportsseveraldifferenttransceiverunits.Theinformationis

mainlypreparedforEK80installationsonavessel.OneormoreWideBandTransceiver

(WBT)unitsareprovided.Fortechnicalspecicationsaboutothertransceivers

supportedbytheEK80,seetherelevantpublications.

Note

AtKongsbergMaritime,wearecontinuouslyworkingtoimprovethequalityand

performanceofourproducts.Thetechnicalspecicationsmaybechangedwithout

priornotice.

Relatedtopics

Technicalspecications,page279

SimradEK80InstallationManual
