Kongsberg Simrad EK80 - Serial Line Splitter Øverland UPC-5000 P

122
394149/D
SeriallinesplitterØverlandUPC–5000P
Onlargeinstallationswithmanyhydroacousticsystems,theseoftenrequirethesame
navigationalinformationfromasinglesensor.Informationsuchascurrentdepthor
speedisprovidedonserialformat.Oneormoreseriallinesplitterscanbeusedto
distributetheinformationfromasinglesensortoseveraldifferentrecipients.
TheØverlandUPC-5000Pisaseriallinesplitterwithtwoseparateinputsandfteen
outputs.
Topics
UPC-5000PSeriallinesplitterdescription,page122
UPC-5000PTechnicalspecications,page123
UPC-5000PConnections,page124
UPC-5000PDimensions,page125
UPC-5000PSeriallinesplitterdescription
TheØverlandUPC-5000Pisaseriallinesplitterwithtwoseparateinputsandfteen
outputs.
Dualpowerinputwithautoswitch.
ThetwoinputsAandBareseparatedwith
Aastheprimaryinput.Ifthereisdataon
bothAandBinputs,inputAisused.Input
BisusedonlyifinputAisidle.Thepower
supplyandbothsignalinputsaregalvanic
isolatedfromtheoutputs.
Alloutputsareshortcircuitprotected.
Informationfromthemanufacturer’ sdata
sheet,copiedMay2014
TheseriallinesplitteristtedwithaDINrailfor
easymountingandreplacement.
Note
Theseriallinesplitterrequiresadedicatedpowersupplyproviding15to30VDC.
Formoreinformationaboutthisseriallinesplitter,consultthemanufacturer’swebsite.
•Manufacturer:Øverland
•Manufacturer’swebsite:http://www.overland.no
SimradEK80InstallationManual
