Kongsberg Simrad EK80 - Split Beam Transducer Connection for Single Beam Use on an Amphenol Socket

394149/D
159
Splitbeamtransducerconnectionforsinglebeamuseonan
Amphenolsocket
AsplitbeamtransducercanbeconnectedtosocketsAandDonacircular12-pin
Amphenoltransducersocket(Type97-12-19S).Thisallowsyoutousethetransduceras
asinglebeamunit.
Theotherendofthecableispermanentlyxedtothe
transducer.
Thetransducerisdesignedwiththeindividualelements
organizedinfourseparatesectors.Itisveryimportant
thatthetransduceriscorrectlyinstalledwiththesectors
positionedasshownintheillustration(seenfrom
above).Eachsectorisconnectedtoadedicatedtransceiverchannel.Inthiscontext,
thephrasetransceiverchannelisusedtodescribeonesinglepathwaythroughthe
transceiver.Thispathwaycontainsonetransmitter,onepreamplierandthenecessary
transmit/receiveswitchingcircuitry.
Note
Westronglyrecommendthatyouinstallthetransducercableinasteelconduit.
Dependingonproductiondate,thetransducercanbedeliveredwithtwodifferentcable
types.Onoldertransducersthecablecontainsblackandwhiteconductors.Onnew
transducersthecablecontainscolourcodedconductors.
Cablelayoutandinterconnections
