Kongsberg Simrad EK80 - Installing the transducer(s)

394149/D
81
5Mountthetopshockabsorberassembly.
aRemovethefourliftinglugs.
bMountthetopshockabsorberassemblyusingtwoofthesameholes.
cUsespareboltstoclosetheremainingliftinglugholes.
6Placecabinetinitscorrectpositiononthebottomframe.
aUsefourboltsthroughthebottomframetosecurethecabinet.
bMountthetopshockabsorberstothebulkheadsupportbracket(s).
7Fastentheearthstrap.
Relatedtopics
InstallingtheEK80hardwareunits,page64
400930WBTCabinetoutlinedimensions,page314
Equipmenthandling,page320
Compasssafedistance,page301
MountingthedrawersintheWBTCabinet
TheWBTCabinetcancontainmaximumsevencustomdrawers.Eachdrawerwillhold
oneWideBandTransceiver(WBT)anditspowersupply.Thedrawerismountedinthe
samewayasanyotherequipmentdesignedfor19"racksusingstandardtools.
Prerequisites
Youmustbeequippedwithastandardsetoftools.Thistoolsetmustcomprisethe
normaltoolsforelectronicandelectromechanicaltasks.Thisincludesdifferent
screwdrivertypes,pliers,spanners,acablestripper,asolderingiron,etc.Eachtool
mustbeprovidedinvarioussizes.Werecommendthatalltoolsaredemagnetizedto
protectyourequipment.
Context
WerecommendthatyoumountalltheemptydrawersintotheWBTCabinetbefore
you
mounttheWideBandTransceiver(WBT)unitoneachdrawer.
InstallingtheEK80hardwareunits
