80
394149/D
Note
Theoutlinedimensionsdrawingshowstheinitialsizeofanemptycabinet.
Whenthecabinetiscompletedfornormaloperation,theweightwillcompress
thebottomshockabsorbersslightly.Youmusttakethisintoconsideration
whenyouplanthemounting.
bDeterminethelocationoftheunit.
cVerifythatthelocationmeetsthesonarroomrequirements
dVerifythatthelocationmeetstheenvironmentalrequirementsdenedfor
theEK80.
eVerifythatthelocationiswithinrangeofthetransducercables.
fMakesurethatthelocationoffersamplespacearoundthecabinettoallowfor
cables,maintenanceandpartsreplacement.
gDeterminetheinstallationmethod.
hMakeallnecessaryinstallationdrawings.
iIfrelevant,designandmanufacturebulkheadsupportbracket(s)and/or"U"
shapedsteelproles.
Note
Theuseof"U"shapedprolesandbulkheadsupportbracket(s)isoptional.
2Mountthe"U"shapedproles.
aDesign,manufactureandmounttheU-shapedsteelproles.
bMakesurethattheprolescanwithstandthefullweightofthecabinet.
cMaketherequiredmountingholestoacceptthebottomframe(withshock
absorbers).
dPositiontheprolesonthedeck,andmountthemusingboltsorwelds.
3Mountthebottomframe.
Thebottomframeisttedwithfourshockabsorbers.IfyouhaveusedU-shaped
proles,placetheframeontopofthese.
4Mountthebulkheadsupportbracket.
aDesignandmanufacturethebulkheadbracket.
bMaketherequiredmountingholestoacceptthetopshockabsorbers.
cPositionthebracketsonthebulkhead,andmountthemusingboltsorwelds.
SimradEK80InstallationManual
