Kongsberg Simrad EK80 - Main system units

394149/D
17
Systemdiagram
ThesystemdiagramidentiesthemaincomponentsofabasicEK80system.Only
themainconnectionsbetweentheunitsareshown.Detailedinterfacecapabilitiesand
powercablesarenotshown.
Inthispublication,thecomputerisreferredtoastheProcessorUnit.
Basicsystem
ThebasicSimradEK80Widebandscienticechosounderconsistsofonetransducer,
oneWideBandTransceiver(WBT)andoneProcessorUnit.Additionaltransceivers
andtransducerscanbeaddedtomeetyouroperationalandfunctionalrequirements.
Post-processingsoftwareisprovidedbythird-partysuppliers.Seeourwebsitefor
moreinformation.
Unlessotherwisespeciedinacontract,thedisplayandtheEthernetswitcharenot
includedinthestandarddeliveryfromKongsbergMaritime.Thesearecommercial
itemsthatcanbepurchasedlocally.
ADisplay
BProcessorUnit
CEthernetswitch
DWideBandTransceiver(WBT)
ETransducers
SystemwithacousticDopplercurrentproler(ADCP)functionality
TheEK80canbeexpandedbyaddingdedicatedhardwareforacousticDopplercurrent
proler(ADCP)measurements.ThefollowingADCPsystemsarecurrentlysupported:
•SimradEC150-3C
SimradEK80
