Wheretoinstallthetransducer
Asingleanswertothequestion"wheretoinstallthetransducer"cannotbegiven.
Thephysicallocationofthetransducerdependsonthevessel'sdesignandconstruction,
howthehullisshaped,andhowthewaterrunsalongthehull.Therearehowevera
numberofimportantguidelines,andsomeoftheseareevenconicting.
Note
Theinformationheremustbeconsideredasgeneraladvice.EachEK80installation
mustbehandledseparatelydependingonthehulldesignandtheotherelectricaland
mechanicalsystemsinstalledonthevessel.
Topics
Mountthetransducerdeep,page48
Avoidprotrudingobjectsnearthetransducer,page49
Mountthetransduceratforwardpartofhulltominimizetheeffectsfromtheow
boundarywaterlayer,page50
Keepthetransducerfarawayfromthepropellers,page51
Mountthetransduceratasafedistancefrombowthruster(s),page51
Summaryandgeneralrecommendations,page52
Mountthetransducerdeep
InordertoachievethebestpossibleEK80performance,mountthetransducerasdeepas
possibleunderthevessel’shull.
Thereareseveralreasonsforthisrecommendation.
Flownoise
Considerthesituationswhenthevesselisunloaded,andpitchinginheavyseas.The
vesselisridinghigh,andthebowmayevenbeliftedoutofthewater.Thiswillcausea
lotofairtofollowtheshapeofthehull.
Theupperwaterlayersoftheseacontainamyriadofsmallairbubblescreatedbythe
breakingwaves.Inheavyseastheupper5to10metresmaybelledwithair,andthe
highestconcentrationswillbenearthesurface.Airbubblesabsorbandreectthesound
energy,andtheymayinworstcasesblockthesoundtransmissionaltogether.
Cavitation
Cavitationistheformationofsmallairbubblesclosetothetransducerface.Thebubbles
appearbecausethelocalpressurebecomesnegativeduringpartsoftheacousticpressure
