Kongsberg Simrad EK80 - Battery Power Cable; K-Sync Interface to Generic RS-232 Synchronization Input

148
394149/D
Batterypowercable
AsuitablecablemustbeprovidedifyouwishtopowertheWideBandTransceiver
(WBT)fromabattery.
Thepowersocketismountedontherearpanel
ofthetransceiver.ThesockettsaConxall4-pin
Mini-Con-X
®
shieldedplug.Onespareplugis
includedwiththeEK80delivery.Youcanuse
thisplugifyouwishtooperatethetransceiver
fromabattery.Theplugcanbeorderedfromthe
manufacturerorpurchasedfromKongsbergMaritime.Usepartnumber390616.
•Manufacturer:SwitchcraftConxall
•Manufacturer’swebsite:http://www.conxall.com
•Truemanufacturer'spartnumber:SF6382–4SG–520
Pinconguration
Pinnumber1234
Voltage
+12VDC0VDC0VDC+12VDC
Minimumcablerequirements
•Conductors:2x1.5mm
2
•Screen:None
•Voltage:60V
•Maximumouterdiameter:Notapplicable
Relatedtopics
Cabledrawingsandspecications,page136
Cablelayoutandinterconnections,page85
K-SyncinterfacetogenericRS-232synchronizationinput
Fortransmissionsynchronizationpurposes,theK-SyncwillinterfaceagenericRS-232
seriallinecommunicationportusingtheCTS(ClearToSend)andRTS(RequestTo
Send)signals.
ThesynchronizedproductisconnectedtotheIOModuleinsidetheK-Sync
SynchronizingUnit.EachIOModuleintheK-SyncSynchronizingUnitprovidessix
connectorsandacongurationboardforphysicaladjustmentsofthecommunication
parameters.
SimradEK80InstallationManual
