394149/D

Relatedtopics

Preparations,page43

Personnelqualications

TheinstallationoftheEK80isademandingtask.Itisveryimportantthatthepersonnel

involvedintheinstallationtasksarecompetentandexperiencedcraftsmen.

Asaminimum,thefollowingcertiedcraftsmenmustbeavailable.

•Navalarchitects

•Welders

•Electricians

•Projectmanager

Note

Thequalityoftheweldingiscriticaltothesafetyofthevessel.Weldingmustonlybe

donebyacertiedwelder.Ifapplicable,thenalinstallationweldsmustbeapprovedby

thevessel’ snationalregistry,thecorrespondingmaritimeauthorityand/orclassication

society.Observetherelevantrulesandregulationsrelatedtowelding.

Relatedtopics

Preparations,page43
