Auxiliaryconnectorforsynchronization
TheWideBandTransceiver(WBT)isttedwithadedicatedsocketforauxiliary
interfaces.
TheAuxiliarysocketontheWideBand
Transceiver(WBT)canbeusedtointerfacean
externalsynchronizationsystem.
ThesockettsaConxall7-pinMini-Con-X
®
shieldedplug.Theconnectionsaremadeonpins
2,3and5.Theplugcanbeorderedfromthe
manufacturerorpurchasedfromKongsbergMaritime.Usepartnumber387563.
•Manufacturer:SwitchcraftConxall
•Manufacturer’swebsite:http://www.conxall.com
•Truemanufacturer'spartnumber:SF6282–7SG–520
Pinnumber1234
Signal
Futureuse
Synchronization
Output
Synchronization
Input
Futureuse
Pinnumber
5
6
7
Signal
DigitalgroundNotusedNotused
Minimumcablerequirements
•Conductors:4x0.5mm
2
•Screen:Overallbraided
•Voltage:60V
•Maximumouterdiameter:Denedbytheplugsand/orthecablegland
Ifyouneedtoinstallaverylongcable,increasethecrosssection.
Relatedtopics
Cabledrawingsandspecications,page136
Cablelayoutandinterconnections,page85
