Kongsberg Simrad EK80 - Test procedures

254
394149/D
2TurnontheEK80,andsetittonormaluse.
3OpentheSetupmenu.
4OntheSetupmenu,selectInstallation.
ObservethattheInstallationdialogboxopens.Thisdialogboxcontainsanumber
ofpagesselectedfromthemenuontheleftside.
5OntheleftsideoftheInstallationdialogbox,selectSynchronization.
6Fromthelistofportsavailable,selectTransceiverAuxiliaryPort.
7ObservethatwhenTransceiverAuxiliaryPortisselected,onlySlavesynchronization
modeispermitted.
SlavemodeisusediftheEK80isgoingtotransmitonlywhenpermittedbya
peripheralsystem.WhenSlavemodeisselected,theEK80doesnottransmit
("ping")unlessanexternaltriggerappearsonthechosensynchronizationport.The
peripheralsystemmaybeanyotherhydroacousticproduct(forexampleanecho
sounderorsonar),orevenadedicatedsynchronizationsystem.
8Atthebottomofthepage,selectApplytosaveyoursettings.
9ContinueyourworkintheInstallationdialogbox,orselectOKtocloseit.
Relatedtopics
SettinguptheEK80inasynchronizedsystem,page126
Cablelayoutandinterconnections,page85
Interfacingperipheralequipment,page228
SettinguptheinterfacebetweentheEK80andtheSimrad
TD50
TheEK80canbesetuptocommunicatewiththeSimradTD503DVisualization
Software.Inthiscontext,theEK80isregardedasthe"sourcesystem".Theinterface
betweentheEK80andtheTD50computerusesahigh-speedEthernetconnection.The
relevantIPaddressesmustbedenedonbothcomputers.
Prerequisites
Itisassumedthatyouarefamiliar
withtheWindows
®
operating
systems,computertechnology,and
interfaceprinciples.
TheEthernetadapterintheEK80
ProcessorUnitissetupwiththecorrectIPaddresses.
SimradEK80InstallationManual
