Kongsberg Simrad EK80 - Mounting the WBT Cabinet

76
394149/D
Relatedtopics
InstallingtheEK80hardwareunits,page64
385609ProcessorUnitdimensions,page310
Equipmenthandling,page320
Compasssafedistance,page301
InstallingtheEthernetswitch
IfyouusemorethanoneWideBandTransceiver(WBT),ahighcapacityEthernet
switchisrequired.TheEthernetswitchisusedtoconnecteachWideBandTransceiver
(WBT)totheProcessorUnit.
Prerequisites
Youmustbeequippedwithastandardsetoftools.Thistoolsetmustcomprisethe
normaltoolsforelectronicandelectromechanicaltasks.Thisincludesdifferent
screwdrivertypes,pliers,spanners,acablestripper,asolderingiron,etc.Eachtool
mustbeprovidedinvarioussizes.Werecommendthatalltoolsaredemagnetizedto
protectyourequipment.
AsuitablelocationforEthernetswitchmustbedenedpriortoinstallation.Ifyouplace
theunitonthebridge,observethecompasssafedistance.
Procedure
1Preparethelocationandthenecessarytools.
2Observetheinstallationrequirements.
aChecktheinstallationrequirementsprovidedbythemanufacturer.
bObservethecompasssafedistance.
cMakesurethatenoughspaceismadeavailableformaintenancepurposes.
dMakesurethattheinstallationmethodallowsforthephysicalvibration,
movementsandforcesnormallyexperiencedonavessel.
Note
Inordertoallowforfuturemaintenance,werecommendtomounttheunitwithits
cablesandconnectorsavailableforeasyaccess.
3Makesurethatthechosenlocationmeetstheinstallationrequirements.
4MounttheEthernetswitchasrecommendedbythemanufacturer.
SimradEK80InstallationManual
