AMountingboltsforthe

WideBandTransceiver

(WBT)

BMountingbracket(not

used)

CHolesforfasteningand

securingthecables

DMountingboltsforthe

drawerassembly

EMountingboltsforthe

drawer

Note

EnsuremaximumphysicaldistancebetweentheWideBandTransceiver(WBT)andthe

PowerSupplyUnit.Thisisimportanttoreducenoise.Placethepowersuppliesona

dedicateddraweratthebottomofthecabinet.

HowtoinstallthecablesintheWBTCabinetisdescribedondrawing444425.The

drawingcanbedownloadedfromourwebsite.Thedrawingisalsoincludedonthe

EK80USB.

Procedure

1Decidewhereinthecabinetyouwishtomountthedrawers.

2Mounteachdrawerusingsixboltsoneachside(D).

3Pulloutthedrawer.

4Removethebracket(B).

5MounttheWideBandTransceiver(WBT)usingtheboltsprovided(A).

Relatedtopics

InstallingtheEK80hardwareunits,page64

400930WBTCabinetoutlinedimensions,page314

Equipmenthandling,page320

Compasssafedistance,page301
