394149/D

Forthemotionsensorunit(MRU)tocommunicatewiththeEK80,itmustsupport

thefollowinginterfaceformat:

•KMBinary

KMBinaryisaproprietarydatagramformatcreatedbyKongsbergMaritimefor

generaluse.Thisformathasveryhighresolutionontimingandsensorparameters.

Note

TheEK80onlyacceptsone datagramformatformotiondata.Ifyouchoosetouse

thisformat,nootherformatsareaccepted.

KongsbergMaritimemayprovideasuitablemotionreferenceunit.Consultyourlocal

dealeroragentformoreinformation.

MotionReferenceUnit(MRU)Ordernumber

Inthebox

SeatexMRU

—

MotionReferenceUnit(MRU)

Documentation

Anordernumberistheuniqueidentierusedwhenaunitoranitemisordered.Thenumberidentiesa

completeunitandrelevantaccessoriespackedinitsshippingcontainer.

Relatedtopics

Additionalrequireditems,page27

Scopeofsupply,page25

SimradEK80,page13
