Kongsberg Simrad EK80 - Personnel qualifications

394149/D
45
Note
Theinstallationshipyardmustprovideallnecessarydesignandinstallation
drawings,aswellastherelevantworkstandardsandmountingprocedures.If
required,alldocumentsprovidedbytheshipyardforthephysicalinstallationof
theEK80mustbeapprovedbythevessel’ snationalregistryandcorresponding
maritimeauthorityand/orclassicationsociety.Suchapprovalmustbeobtained
beforetheinstallationcanbegin.Theshipownerandshipyarddoingtheinstallation
areresponsibleforobtainingandpayingforsuchapproval.
Relevantinstallationdrawingsareincludedwitheachtransducer.Thedrawings
(normallyinAutoCadformat)canbedownloadedfromourwebsite.
3InstalltheEK80systemunits.
NotethatsomeEK80systemunitsmaybecommercial.Unlessorderedspecically
thesearenotincludedinthedelivery,andmustbepurchasedlocally.
•InstallingtheEK80hardwareunits,page64
4InstallthecablesbetweentheEK80systemunits.
Observetherelevantcableplan,procedures,aswellasthegeneralrequirementsfor
cabling.ThisisdescribedintheCablelayoutandinterconnectionschapter.Observe
therelevantcableplan,procedures,aswellasthegeneralrequirementsforcabling.
•Cablelayoutandinterconnections,page85
5InstallthecablesbetweentheEK80andtherelevantperipheraldevices.
6TurnontheEK80forthersttime,andsetittowork.
Note
InordertoturnontheEK80inasafeandcorrectmanner ,therelevantprocedures
mustbecompliedto!
•Settingtowork,page185
7DoacompleteEK80systemtest.
ThetestsaredescribedinSettingtoworkchapterinthismanual.Theyarealso
providedintheHarbourAcceptanceTestandtheSeaAcceptanceTestdocuments.
•Settingtowork,page185
Furtherrequirements
FillinandsigntheInstallationRemarksform,andsendittotheSimradsupport
departmentasspeciedontheform.
Relatedtopics
Preparations,page43
Preparations
