394149/D

Ifthevesselhullhasabulbousbow,thismaywellbeagoodtransducerlocation,but

alsointhiscasetheowpatternoftheaeratedwatermustbetakenintoconsideration.

Theforemostpartofthebulbisoftenagoodlocation.

AThruster

BTransducerlocation

Thisappliestothevesselinnormaltrimandspeed.

Important

Thetransducermustnot haveanegativeinclinationanglecomparedtowaterow.

Donotplaceatransducerinthevicinityofprotrudingobjects,andespeciallynotclose

behindthem.

Makesurethatthesurfaceoftheresultinginstallationisassmoothandstreamlinedas

possible.

Relatedtopics

Wheretoinstallthetransducer,page48

Preparations,page43
