66
394149/D
2Observetheinstallationrequirements.
aDependingonthelocalrequirementsandpreferences,theWideBand
Transceiver(WBT)canbeinstalledonthebulkhead,insideaconsole,ina
cabinetor19”rack,oronadesk.
bThepositionmustbechosentottheavailablecablelengthsbetweentheWide
BandTransceiver(WBT)andtheotherunitsitconnectsto.Shortdistanceto
thetransducerisalwaysrstpriority.
cIfyouplacingtheWideBandTransceiver(WBT)onthebridge,observethe
compasssafedistance.
dMakesurethatenoughspaceismadeavailableformaintenancepurposes.
eMakesurethatadequateventilationisavailabletoavoidoverheating.
fMakesurethattheinstallationmethodallowsforthephysicalvibration,
movementsandforcesnormallyexperiencedonavessel.
Note
Inordertoallowforfuturemaintenance,werecommendtomounttheunitwithits
cablesandconnectorsavailableforeasyaccess.
3Makesurethatthechosenlocationmeetstheinstallationrequirements.
4PlacetheWideBandTransceiver(WBT)intheselectedposition.
5Securetheunitusingfour5mmbolts.
6Connectthecables.
Note
Whenyouconnectthecables,makesurethattheyareallproperlysecured,andable
towithstandthevibrationandmovementsofthevessel.
Relatedtopics
InstallingtheEK80hardwareunits,page64
388697WideBandTransceiver(WBT)outlinedimensions,page308
Equipmenthandling,page320
Compasssafedistance,page301
