6-5
bizhub PRESS C71cf
6
6 Lever [M1] Opens leftward to withdraw the conveyance fixing unit for re-
moval of paper jam.
7 Fixing unit Fuses toner onto paper.
8 Leaf spring (back) Stabilizes the media conveyance. Also it prevents glue from
sticking to the conveyance section.
9 Leaf spring (front) Stabilizes the media conveyance. Also it prevents glue from
sticking to the conveyance section.
10 Cover [M2] Opens when removing paper jammed inside the main body or
when cleaning.
11 Pre-transfer roller 1 Conveys the media.
12 Cover [M3] Opens when removing paper jammed inside the main body or
when cleaning.
13 Pre-transfer roller 2 Conveys the media.
14 Secondary transfer roller Transfers toner to media.
No. Name Description
