Konica Minolta C71cf - Adjusting the Position of the Tension Roller 2 (Top;Bottom)

3-15
bizhub PRESS C71cf
3
)Adjusting the Position of the Tension Roller 2 (top/bottom)
Adjust the tension with the position of the tension roller 2 (top/bottom).
A Push down the front and back tabs located on the tension roller 2 to unlock the roller.
When changing the roller position from Top  Bottom:
When changing the roller position from Bottom
 Top:
B Move the tension roller 2 in the groove.
If you want to raise the tension, move it "Top". If you want to lower the tension, move it "Bottom".
