3-7
bizhub PRESS C71cf
3
Connect the Media Using the workbench
NOTICE
Be sure to join the edge of the media with that of another one. If media to be joined overlaps, it may cause a paper jam.
A Insert the end of the media from the bottom of the media pressing bar 1.
B Put the rear end of the cut media on the front end of the media to join, and then press
WEB GRIPPER1 of Roll Winder RW-101 to hold the media.
C Cut the media with following the cutter groove on the workbench.
After cutting, take the overlapped part away.
Be careful not to cut your hand when cutting the media.
WEB
GRIPPER2
WEB
GRIPPER1
EMG.RESET
READY JOG
STOP
To Next Page
