bizhub PRESS C71cf
6
)Delivering section
WARNING
WARNING
WARNI NG
NEVER throw the waste toner box into a fire.
- Otherwise, the toner may ignite and cause a dangerous situation.
- For details about handling the waste toner box, contact your service representative.
CAUTION
CAUTION
DO NOT put your hand into the fixing unit of the conveyance fixing unit.
- Otherwise, you may get burned. Be especially careful when pulling out the conveyance fixing unit
or opening the fixing unit.
CAUTION
CAUTION
DO NOT put your hand or arm between the main body and conveyance fixing unit.
- Touching a connection terminal or other electric parts may damage the machine or cause
unexpected trouble. Please do not try to work yourself, but contact your service representative.
CAUTION
CAUTION
DO NOT pull out the toner bottle other than the time to exchange for running out of toner.
- If you pull out the toner bottle in which the toner remains, an area nearby may become dirty with
toner.
1
2
3
4
5
No. Name Description
1 Top cover of the delivering section Protects the delivering section. Remove in case of the mainte-
nance.
2 Feeding knob Turn to the right to feed media manually.
3 Upper delivering roller Delivers the printed media from the main body.
4 Lower delivering roller Delivers the printed media from the main body.
5 Guide plate Holds the media.
