MIDI Implementation Chart
Date : 2009.12.9
microSTATION
*C
*E, *5
*1
*1
*1
*1
*P
Memorized
[Music Workstation]
Polyphonic aftertouch and Channel aftertouch
*A (receive)
transmitted only as sequence data
*A (receive)
All note numbers 0–127 can be transmitted
by the Arpeggiator or as sequence data
0, 32
1, 2, 17, 19, 20, 21
4, 5, 7, 8, 10
11, 12, 13
64, 65, 66, 67
70–79
16, 80, 81, 82, 83
91, 92, 93, 94, 95
14, 22, 23, 24, 31
6, 38, 96, 97
100, 101
0–119
0–119
120, 121
Notes *P, *A, *C, *E:
Transmitted/received when Global/Media MIDI Filter (Program Change, Aftertouch, Control Change, SysEx) is Enable, respectively.
*1: When
Global/Media
MIDI Clock is Internal, transmitted but not received. The opposite for Ext.MIDI/Ext.USB.
*2: Valid if assigned as a MIDI control change in
Global/Media
Controllers. The number shown here is the CC default assignment.
*3: RPN (LSB,MSB)=00,00: Pitch bend range, 01,00: Fine tune, 02,00: Coarse tune
*4: Valid if assigned as a MIDI control change in
Global/Media
External Setup.
*5:
In addition to Korg exclusive messages, Inquiry, GM System On, Master Volume, Master Balance, Master Fine Tune, and Master Coarse
Tune are supported.
System
Real Time
Clock
Command
Aux
Messages
Function Transmitted Recognized Remarks
Basic
Channel
Default
Changed
Aftertouch
Pitch Bend
Polyphonic (Key)
Monophonic (Channel)
Program
Change
Variable Range
System Exclusive
System
Common
Song Position
Song Select
Tune
Velocity
Note
Number:
True Voice
Mode
Memorized
Messages
Altered
Control
Change
Mode 1: OMNI ON, POLY Mode 2: OMNI ON, MONO : Yes
Mode 3: OMNI OFF, POLY Mode 4: OMNI OFF, MONO : No
0 – 127
9n, V=1 – 127
0 – 127
0 – 127
1 – 16
1 – 16
0 – 127
0 – 127
9n, V=1 – 127
0 – 127
0 – 127
0 – 127
123 – 127
1 – 16
1 – 16
3
