Korg RK-100S Parameter Guide

62
RK-100S parameter guide
24 019 57 045 90 071 123 97
25,26 020 58,59 046 91,92 072 124 98
27 021 60 047 93 073 125,126 99
28 022 61 048 94 074 127 100
29 023 62 049 95 075
30,31 024 63,64 050 96,97 076
32 025 65 051 98 077
For example if you want to switch the arpeggiator on/o from an external MIDI
sequencer, make the following seings.
O: CC#99: 0, CC#98: 2, CC#6: 0...63
On: CC#99: 0, CC#98: 2, CC#6: 64...127
Controlling the Timbre parameters
These messages are received on the Global MIDI channel.
Virtual Patch Source
Source1...Source5: [Bn, 63, 04, Bn, 62, 00...04, Bn, 06, mm]
(n: channel, mm: parameter value)
MSB (Hex) LSB (Hex) Value (received)
Patch1 Source 04 (04) 00 (00)
0...9: FILTER EG, 10...19: AMP EG,
20...29: ASSIGNABLE EG, 30...40: LFO1,
41...48: LFO2, 49...58: Velocity,
59...68: Short ribbon (Pitch),
69...78: Short ribbon (Modulation),
79...88: Keyboard Track,
89...97: MIDI Control 1,
98...107: MIDI Control 2,
108...117: MIDI Control 3
118...127: Long Ribbon (Filter)
Patch2 Source 04 (04) 01 (01)
Patch3 Source 04 (04) 02 (02)
Patch4 Source 04 (04) 03 (03)
Patch5 Source 04 (04) 04 (04)
Virtual Patch Destination
Destination1...Destination5: [Bn, 63, 04, Bn, 62, 08...0D, Bn, 06, mm ]
(n: channel, mm: parameter value)
MSB (Hex) LSB (Hex) Value (received)
Patch1
Destination
04(04) 08(08)
0...2: Pitch, 3...5: OSC2 Tune, 6...9: OSC1 Control 1,
10...12: OSC1 Level, 13...15: OSC2 Level, 16...18: NOISE Level,
19...21: Filter1 Type Balance, 22...25: Filter1 Cuto,
26...28: Filter1 Resonance, 29...31: Filter2 Cuto,
32...34: Drive/WS Depth, 35...37: AMP Level,
38...41: Panpot, 42...44: LFO1 Frequency,
45...47: LFO2 Frequency, 48...50: Portamento,
51...53: OSC1 Control 2, 54...57: Filter1 FILTER EG Int,
58...60: Filter1 Key Track, 61...63: Filter2 Resonance,
64...66: Filter2 FILTER EG Int, 67...69: Filter2 Key Track,
70...73: FILTER EG Aack, 74...76: FILTER EG Decay,
77...79: FILTER EG Sustain, 80...82: FILTER EG Release,
83...85: AMP EG Aack, 86...89: AMP EG Decay,
90...92: AMP EG Sustain, 93...95: AMP EG Release,
96...98: ASSIGNABLE EG Aack,
99...101: ASSIGNABLE EG Decay,
102...105: ASSIGNABLE EG Sustain,
106...108: ASSIGNABLE EG Release,
109...111: Patch1 Int, 112...114: Patch2 Int,
115...117: Patch3 Int, 118...121: Patch4 Int,
122...124: Patch5 Int, 125...127: Long Ribbon (Filter) Int
Patch2
Destination
04(04) 09(09)
Patch3
Destination
04(04) 10(0A)
Patch4
Destination
04(04) 11(0B)
Patch5
Destination
04(04) 12(0C)

Korg RK-100S Specifications

General

Polyphony	8 voices
Arpeggiator	Yes
Type	Keytar
LFO	2 LFOs
Keyboard	37 keys (velocity sensitive)
Sound Engine	Analog modeling
Inputs	Audio input
Outputs	1 x 1/4" (audio)
Power Supply	6 x AA batteries or AC adapter
Dimensions	830 x 262 x 71 mm / 32.68 x 10.31 x 2.80 inches
Weight	3.4 kg / 7.50 lbs (excluding batteries)
Effects	Delay
Controllers	Ribbon controller
MIDI	Out
USB	Type B
Oscillators	2 oscillators
