Korg RK-100S - Controlling the Vocoder Parameters; Other Controls; Voice Mode

63
MIDI
Controlling the vocoder parameters
These messages are received on the Global MIDI channel.
Fc Modulation Source
FC.MOD.SRC (Fc Modulation Source): [Bn, 63, 04, Bn, 62, 00, Bn, 06, mm]
(n: channel, mm: parameter value)
Fc Mod Sorce Value (received)
FILTER EG 0...10
AMP EG 11...20
ASSIGNABLE EG 21...31
LFO1 32...42
LFO2 43...52
Velocity 53...63
Short Ribbon (Pitch) 64...74
Short Ribbon (Modulation) 75...84
Keyboard Track 85...95
MIDI Control 1 96...106
MIDI Control 2 107...116
MIDI Control 3 117...127
Band parameters
You can control the output level and pan for each band of the vocoder’s synthesis
lter.
Level 1...Level16: [Bn, 63, 04, Bn, 62, 40...4F, Bn, 06, mm]
Pan1...Pan16: [Bn, 63, 04, Bn, 62, 50...5F, Bn, 06, mm]
(n: channel, mm: parameter value)
Vocoder Sw
Vocoder Sw: [Bn, 63, 05, Bn, 62, 04, Bn, 06, mm]
(n: channel, mm: parameter value)
MSB (Hex) LSB (Hex) Value (transmied) Value (received)
Vocoder Sw 05(05) 04(00) 0...63:OFF, 64...127: ON
Other controls
These messages are received on the Global MIDI channel.
Voice Mode
Voice Mode: [Bn, 63, 05, Bn, 62, 00, Bn, 06, mm]
(n: channel, mm: parameter value)
MSB (Hex) LSB (Hex) Value (received)
Voice Mode 05(05) 00(00)
0...31: SINGLE,
32...63: LAYER ,
64...95: SPLIT,
96...127: MULTI
