Krone 1022623 - Malfunction, Cause and Remedy; Disturbances at the Pick-Up or During Picking up of Crops

Malfunction, cause and remedy 19
Disturbances at the pick-up or during picking up of crops 19.1
Comprima F 155
Original Operating Instructions 150001049_01_en 211
19 Malfunction, cause and remedy
WARNING
Risk of injury due to non-observance of relevant safety notices
If the relevant safety notices are not observed, persons may get seriously injured or killed.
 To avoid accidents, the basic safety instructions must be read and observed, refer to
page15.
WARNING
Risk of injury due to non-observance of safety instructions
If the relevant safety routines are not observed, persons may be seriously injured or killed.
 The safety routines must be read and observed to avoid accidents, refer to page27.
19.1 Disturbances at the pick-up or during picking up of crops
Malfunction: The pick-up cannot be lowered.
Possible cause Remedy
There was no switchover to
pick-up on the terminal.
 Pre-select pick-up on the terminal by pressing the
key.
The hydraulic hose has not
been inserted in the tractor.
 Correctly connect the hydraulic hose for the pick-up, refer to
page55.
The working height of the
pick-up is set too high that the
pick-up cannot be lowered.
 Set the working height of the pick-up, refer to page80.
Malfunction: There are crop blockages in the intake area.
CAUTION!Machine damage due to crop blockages! Immediately stop, switch off PTO
shaft and remove the crop blockages.
Possible cause Remedy
The swaths are uneven or too
large.
 Divide the swaths.
The tractor driver is driving too
fast.
 Reduce the driving speed.
 Slow down at the beginning of the baling process until the
picked up crops roll into the bale chamber.
The machine height has not
been set correctly with respect
to the tractor.
 Set the machine correctly using the drawbar from the
KRONE service partner, refer to page47.
The crop press roller unit has
been set too low.
 Set the crop press roller unit higher, refer to page81.
